8WH12010CK07

PE-Terminal Insta 16 mm2 YE/GN screw

Manufacturer's No: 8WH1201-0CK07     Manufacturer: Siemens
PE-Terminal Insta 16 mm2  YE/GN screw

Availability On Request

£11.94
  • Terminal type: Screw terminal
  • Installation terminal size: 16 mm²
  • Color: Green-yellow
  • Features PE/PEN terminal


Product

Manufacturer Material ID -
8WH1201-0CK07
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85369010
Country of Origin -
DE
Export Control Regulations -
AL: N / ECCN: EAR99
UNSPSC -
39121410

Technical Specification

Closing plate required -
Connectable conductor cross section fine-strand with cable end sleeve -
6 Square millimetre
Connectable conductor cross section fine-strand without cable end sleeve -
6 Square millimetre
Connectable conductor cross section multi-wired -
2.5 Square millimetre
Connectable conductor cross section solid-core -
6 Square millimetre
Depth -
12.2 Millimetre
Height -
49.5 Millimetre
Inflammability class of insulation material acc. with UL94 -
V2
Mounting method -
DIN rail (top hat rail) 35 mm
Number of clamp positions per level -
2
Number of levels -
1
Operating temperature -
-60 Degrees celsius
Type of electrical connection 1 -
Screw connection
Type of electrical connection 2 -
Screw connection
Width -
50 Millimetre

Availability On Request

£11.94
