1SBL357201R7000

AF50-40-00 100-250V 50Hz / 100-250V 60Hz / 100-250V DC Contactor

Manufacturer's No: AF50-40-00     Manufacturer: ABB
AF50-40-00 100-250V 50Hz / 100-250V 60Hz / 100-250V DC Contactor

Availability Back Order

£521.73
  • AF50-40-00 4-pole contactor for controlling non-inductive or slightly inductive loads
  • Suitable for power circuits up to 690V AC and 440V DC
  • Electronic coil interface accepts wide control voltage range (100-250V AC/DC)
  • Can be used for various applications including lighting
  • Wide voltage range capability (100-250V AC/DC)
  • Reduced power consumption
  • Distinct closing and opening actions
  • Noise-free operation
  • Can withstand voltage interruptions or dips in control supply (? 20 ms)
  • Block type design with 4 N.O. main poles

Read more

  • Front and side-mounted add-on auxiliary contact blocks
  • AC or DC control circuit operation
  • Wide range of available accessories


Product

Manufacturer Material ID -
AF50-40-00
Net Weight -
1.42kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
FR
Minimum Order Quantity -
1
UNSPSC -
32151705

Technical Specification

Rated operation current Ie at AC-4, 400 V -
- Ampere
Rated operation power at AC-4, 400 V -
- Kilowatt
Rated control supply voltage Us at AC 50HZ -
100 Volt
Rated control supply voltage Us at AC 60HZ -
100 Volt
Rated control supply voltage Us at DC -
100 Volt
Rated operation power at AC-3, 400 V -
22 Kilowatt
Number of main contacts as normally open contact -
4
Number of normally closed contacts as main contact -
0
Number of auxiliary contacts as normally open contact -
0
Number of auxiliary contacts as normally closed contact -
0
Rated operation current Ie at AC-3, 400 V -
50 Ampere
Rated operation current Ie at AC-1, 400 V -
100 Ampere
Rated control supply voltage at AC 50 Hz -
100 Volt
Rated control supply voltage at AC 60 Hz -
100 Volt
Rated control supply voltage at DC -
100 Volt
Type of electrical connection of main circuit -
Screw connection
Voltage type for actuating -
AC/DC
