1058600

Magnetic Field Sensor, For Pneumatic Cylinders

Manufacturer's No: BIM-NST-Y1X-H1141     Manufacturer: Turck Banner
Magnetic Field Sensor, For Pneumatic Cylinders

Availability On Request

POA
  • Magnetic Field Sensor for Pneumatic Cylinders
  • Material: Plastic (PA12-GF30)
  • Technology: Magnetic-inductive sensor
  • Power Supply: DC 2-wire, 8.2 VDC
  • Output: DIN EN 60947-5-6 (NAMUR)
  • Connector: Male M12 x 1
  • ATEX Certified: II 2 G (Ex Zone 1), II 1 D (Ex Zone 20)
  • Safety Integrity Level (SIL): SIL 2 (Low Demand Mode) per IEC 61508, PL c per ISO 13849-1 at HFT0; SIL 3 (All Demand Mode) per IEC 61508, PL e per ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
BIM-NST-Y1X-H1141
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
PL
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-25 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 2G
Height of sensor -
14 Millimetre
Housing material -
Plastic
Length of sensor -
28 Millimetre
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
2
Suitable for safety functions -
Type of actuation -
Magnet
Type of electric connection -
Plug-in connection
Type of switching output -
NAMUR
Voltage type -
DC
Width sensor -
17 Millimetre
