1080025

Inductive Sensor

Manufacturer's No: BI15-Q20-Y1X-H1141     Manufacturer: Turck Banner
Inductive Sensor

Availability On Request

£65.67
  • Inductive Sensor
  • Rated switching distance: 15 mm
  • Flush, Rectangular design with a height of 20 mm
  • Active face on top
  • Material: Plastic (PBT-GF30-V0)
  • DC 2-wire, nominal voltage: 8.2 VDC
  • Output according to DIN EN 60947-5-6 (NAMUR)
  • M12 x 1 male connector
  • ATEX category II 2 G, Ex Zone 1
  • ATEX category II 1 D, Ex Zone 20

Read more

  • SIL 2 (Low Demand Mode) according to IEC 61508, PL c according to ISO 13849-1 at HFT0
  • SIL 3 (All Demand Mode) according to IEC 61508, PL e according to ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
BI15-Q20-Y1X-H1141
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Construction type housing -
Cuboid
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 2G
Height of sensor -
20 Millimetre
Housing material -
Plastic
Length of sensor -
68 Millimetre
Mechanical mounting condition for sensor -
Concise
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
None
Suitable for safety functions -
Switching distance -
15 Millimetre
Switching frequency -
1000 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Plug-in connection
Type of switching output -
NAMUR
Voltage type -
DC
Width sensor -
40 Millimetre
Turck Banner

Availability On Request

£65.67
