1SVR730712R1400

CM-MSS.31S Therm. motor protec. relay 1n/o+1n/c, 24-240VAC/DC

Manufacturer's No: CM-MSS.31S     Manufacturer: ABB
CM-MSS.31S Therm. motor protec. relay 1n/o+1n/c, 24-240VAC/DC

Availability Back Order

£146.75
  • Model: CM-MSS.31S Thermistor Motor Protection Relay
  • Control Supply Voltage: 24-240 VAC/DC
  • Output: 1 Normally Open (N/O) + 1 Normally Closed (N/C) contacts rated at 250 V/4 A
  • Sensor Circuit: Monitors PTC temperature sensors using closed-circuit principle
  • Short-circuit and interrupted-wire monitoring for sensor circuit
  • Reset options: Automatic, manual, or remote
  • Certification: ATEX directive 94/9/EC compliant
  • Features reset/test button and sealable transparent cover for protection
  • Connection: Screw connection technology with double-chamber cage connection terminals


Product

Manufacturer Material ID -
CM-MSS.31S
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121529

Technical Specification

Rated control supply voltage Us -
24 Volt
Width -
22.5 Millimetre
Height -
85.6 Millimetre
Depth -
103.7 Millimetre
Rated control supply voltage -
24 Volt
Number of measuring circuits -
1
External reset possible -
Connection type auxiliary circuit -
Screw connection
Voltage type for actuating -
AC/DC
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
1
Number of contacts as change-over contact -
0
ABB

Availability Back Order

£146.75
