1SVR405501R4010

CR-S048VDC1R Pluggable interface relay 1c/o, A1-A2=48VDC, Output=6A/250VAC

Manufacturer's No: CR-S048VDC1R     Manufacturer: ABB
CR-S048VDC1R Pluggable interface relay 1c/o, A1-A2=48VDC, Output=6A/250VAC

Availability On Request

£7.50
  • Model: CR-S048VDC1R
  • Pluggable interface relay
  • Control Supply Voltage: 48V DC
  • Output: 1 c/o (SPDT), 6A/250VAC
  • Slim design, 6.2mm wide
  • Suitable for direct mounting on PCB or with ABB's sockets
  • Can be snap-on mounted onto DIN Rail
  • Used for electrical isolation, amplification, and signal matching
  • UL 94-V0 certified for high flame retardation
  • Accessories available: screw and spring sockets, jumper bars, markers


Product

Manufacturer Material ID -
CR-S048VDC1R
Net Weight -
0.01kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
CN
UNSPSC -
39121529

Technical Specification

Rated control supply voltage Us at AC 50HZ -
0 Volt
Rated control supply voltage Us at AC 60HZ -
0 Volt
Rated control supply voltage Us at DC -
48 Volt
Degree of protection (IP) -
IP20
Degree of protection (IP rating) -
IP20
Depth -
28 Millimetre
Drive, polarization -
Polarized
Drive, switching attitude -
Mono stable
Height -
15 Millimetre
Material contact -
Silver tin oxide (AgSnO2)
Material of contact surface -
Other
Nominal current -
6 Ampere
Number of contacts as change-over contact -
1
Number of contacts as normally closed contact -
0
Number of contacts as normally open contact -
0
Rated control supply voltage at DC -
48 Volt
Relay technology category according to IEC 61810-7 -
RT I
Type of electric connection -
Plug-in connection
Type of switch contact -
Single contact
Voltage type (operating voltage) -
AC/DC
Voltage type for actuating -
DC
Width -
5 Millimetre
ABB

Availability On Request

£7.50
