2CSR255140R1105

DS201 B10 A30 - RCBO

Manufacturer's No: DS201 B10 A30     Manufacturer: ABB
DS201 B10 A30  - RCBO

Availability Back Order

POA
  • DS201 B10 A30 RCBO
  • 1P+N in two-modules device
  • Protects single-phase circuits from overload and short-circuit currents
  • Protects against earth fault currents
  • Provides protection against indirect and direct contacts (sensitivity = 30 mA)


Product

Manufacturer Material ID -
DS201 B10 A30
Net Weight -
0.24kg

Additional Product Information

Country of Origin -
IT
Minimum Order Quantity -
1
UNSPSC -
32151705

Technical Specification

Disconnection characteristic -
UN
Voltage type -
AC
Built-in depth -
69 Millimetre
Rated current -
10 Ampere
Rated voltage -
230 Volt
Release characteristic -
B
Rated fault current -
0.03 Ampere
Leakage current type -
A
Surge current capacity -
0.25 kiloampere
Current limiting class -
3
Over voltage category -
3
Pollution degree -
2
Width in number of modular spacings -
2
Frequency -
50/60 Hz
Degree of protection (IP) -
IP2X
Number of protected poles -
1
Concurrently switching N-neutral -
Rated short-circuit breaking capacity IEC 60947-2 -
10 kiloampere
Number of poles (total) -
2
