SK827041-AF

EK550-40-11 110V 50Hz / 120V 60Hz Contactor

Manufacturer's No: EK550-40-11-110V     Manufacturer: ABB
EK550-40-11 110V 50Hz / 120V 60Hz Contactor

Availability On Request

£3,392.13
  • EK550-40-11 Contactor
  • 4-pole contactor
  • Suitable for distribution and railway applications
  • Operates with control voltage
  • Voltage options: 110V 50Hz / 120V 60Hz, 24-690V AC, 24-220V DC
  • Suitable for AC and DC switching


Product

Manufacturer Material ID -
EK550-40-11-110V
Net Weight -
17.50kg

Additional Product Information

Commodity Code -
85364900
Country of Origin -
BG
Minimum Order Quantity -
1
UNSPSC -
39121529

Technical Specification

Rated control supply voltage Us at DC -
- Volt
Rated operation current Ie at AC-4, 400 V -
- Ampere
Rated operation power at AC-4, 400 V -
- Kilowatt
Rated control supply voltage Us at AC 50HZ -
110 Volt
Rated control supply voltage Us at AC 60HZ -
120 Volt
Depth -
225.5 Millimetre
Height -
272 Millimetre
Number of auxiliary contacts as normally closed contact -
1
Number of auxiliary contacts as normally open contact -
1
Number of main contacts as normally open contact -
4
Number of normally closed contacts as main contact -
0
Rated control supply voltage at AC 50 Hz -
110 Volt
Rated control supply voltage at AC 60 Hz -
120 Volt
Rated operation current Ie at AC-1, 400 V -
800 Ampere
Rated operation current Ie at AC-3, 400 V -
550 Ampere
Rated operation power at AC-3, 400 V -
280 Kilowatt
Type of electrical connection of main circuit -
Rail connection
Voltage type for actuating -
AC
Width -
270 Millimetre
ABB

Availability On Request

£3,392.13
