1SAE341111R0631

ESB40-31N-06 Installation Contactor (NC) 30 A - 3 NO - 1 NC - 230 V - Control Circuit 400 Hz

Manufacturer's No: ESB40-31N-06     Manufacturer: ABB
ESB40-31N-06 Installation Contactor (NC) 30 A - 3 NO - 1 NC - 230 V - Control Circuit 400 Hz

Availability Back Order

£162.20
  • Model: ESB40-31N-06 Installation Contactor (NC)
  • Current Rating: 30 A
  • Contact Configuration: 3 Normally Open (NO), 1 Normally Closed (NC)
  • Voltage: 230 V
  • Control Circuit Frequency: 400 Hz
  • Suitable for single and three-phase loads up to 40 A
  • Can be operated by AC or DC
  • Designed for household and industrial use
  • Features hum-free operation
  • Low power consumption

Read more

  • Integrated overvoltage protection
  • Offers various contact combinations and accessories


Product

Manufacturer Material ID -
ESB40-31N-06
Net Weight -
0.41kg

Additional Product Information

Commodity Code -
85365080
UNSPSC -
39122330

Technical Specification

Utility category -
7
Additional equipment possible -
Degree of protection (IP rating) -
IP20
Hum-free -
Number of contacts as normally closed contact -
1
Number of contacts as normally open contact -
3
Rated excitation voltage -
230 Volt
Rated operating voltage -
220 Volt
Rated operation current -
40 Ampere
Recess depth -
58 Millimetre
Utilization category according to EN IEC 60947-4-1 -
AC-1
Voltage type (excitation voltage) -
AC/DC
Voltage type (operating voltage) -
AC/DC
Width in number of modular spacings -
3
ABB

Availability Back Order

£162.20
