7TCA085460R0103

ESP 415/III/TNS Surge Protective Device

Manufacturer's No: ESP415IIITNS     Manufacturer: ABB
ESP 415/III/TNS Surge Protective Device

Availability Back Order

POA
  • Surge Protective Device: ESP 415/III/TNS
  • Type: Type 1+2
  • Voltage: Single phase 415V TNS supplies
  • Surge Current Capacity: 12.5kA 10/350


Product

Manufacturer Material ID -
ESP415IIITNS
Net Weight -
0.69kg

Additional Product Information

Country of Origin -
SI
Minimum Order Quantity -
1
UNSPSC -
39122330

Technical Specification

Nominal voltage DC -
- Volt
Max. continuous voltage DC -
- Volt
Max. PV-voltage -
- Volt
Mounting method -
DIN rail (top hat rail) 35 mm
Construction size -
4 modular spacing
Voltage protection level -
1.4 Kilovolt
Max. continuous voltage AC -
320 Volt
Nominal discharge surge current (8/20) -
25 kiloampere
Nominal voltage AC -
240 Volt
Category type 2 -
Voltage protection level L-N -
1.4 Kilovolt
Signalling at the device -
Optic
Degree of protection (IP) -
IP20
Voltage protection level N-PE -
1.4 Kilovolt
Integrated backup fuse -
Max. conductor cross section solid (solid, stranded) -
25 Square millimetre
Max. conductor cross section flexible (fine-strand) -
25 Square millimetre
ABB

Availability Back Order

POA
