Flow Monitoring, Inline Sensor with Integrated Processor

Manufacturer's No: FCI-34D10A4P-AP8X-H1141     Manufacturer: Turck Banner
Flow Monitoring, Inline Sensor with Integrated Processor

Availability On Request

£702.37
  • Flow Monitoring Inline Sensor with Integrated Processor
  • Operating Voltage: 19.2-28.8 VDC
  • Flow Sensor for liquid media using Calorimetric principle
  • Adjustable operating range: 0.1-6 l/min
  • Sensor material: Stainless steel A4 (1.4404)
  • Mechanical Connection: Tri-Clamp
  • Temperature range: -20 to +80 °C
  • DC 3-wire, NO contact, PNP output
  • Connector device: M12 x 1


Product

Manufacturer Material ID -
FCI-34D10A4P-AP8X-H1141
Net Weight -
0.36kg

Additional Product Information

Commodity Code -
90261021000
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Ambient temperature for evaluation electronic -
0 Degrees celsius
Compressive strength measuring head -
20 Pressure
Measurement principle -
Thermal
Type of electric connection -
Plug-in connection
Type of process connection -
Flange connector
Turck Banner

Availability On Request

£702.37
