7525104

Flow Monitoring, For the Connection of FCS and FCI Product Series Flow Sensors

Manufacturer's No: FM-IM-2UPLI63X     Manufacturer: Turck Banner
Flow Monitoring, For the Connection of FCS and FCI Product Series Flow Sensors

Availability On Request

£339.07
  • Flow monitoring device for connecting FCS and FCI product series flow sensors
  • IO-Link device with current and transistor outputs
  • Operating voltage: 20-30 VDC
  • Analog output for flow measurement
  • Transistor switching outputs for temperature and fault indication
  • LED band for displaying flow rate and media temperature
  • Monitoring of operating and display range
  • Detection of wire-break and short-circuit on sensor side
  • Standard IO or IO-Link operating mode
  • Parameter adjustment via pushbutton or software-supported through IO-Link


Product

Manufacturer Material ID -
FM-IM-2UPLI63X
Net Weight -
0.23kg

Additional Product Information

Commodity Code -
90262020000
Country of Origin -
DE
UNSPSC -
39121402

Technical Specification

Ambient temperature for evaluation electronic -
-25 Degrees celsius
Type of electric connection -
Other
Turck Banner

Availability On Request

£339.07
