50139650

Diffuse sensor with background suppression Operating range limit: 0.005 ... 0.8 m; Light source: Laser, Red; Protection class: 2;

Manufacturer's No: HT25CL2/2N     Manufacturer: Leuze
Diffuse sensor with background suppression Operating range limit: 0.005 ... 0.8 m; Light source: Laser, Red; Protection class: 2; Shift angle: Typ. ± 1,5°; Supply voltage: 10 ... 30 V, DC; Dig

Availability On Request

£236.00
  • Operating Range: 0.005m to 0.8m
  • Light Source: Red Laser
  • Shift Angle: ±1.5°
  • Supply Voltage: 10V to 30V DC
  • Digital Switching Outputs: 2
  • Switching Output 1: NPN Transistor, Light switching
  • Switching Output 2: NPN Transistor, Dark switching
  • Switching Frequency: 2,500 Hz
  • Connection: 4-wire Cable, 2,000mm
  • Housing Design: Cubic

Read more

  • Dimensions: 15mm x 42.7mm x 30mm
  • Housing Material: Plastic
  • Operational Controls: Multiturn Potentiometer
  • Ambient Temperature Range: -40°C to 60°C
  • Degree of Protection: IP67, IP69K

Accessories



Product

Manufacturer Material ID -
HT25CL2/2N
Net Weight -
0.02kg

Additional Product Information

Commodity Code -
85365019
Country of Origin -
DE
UNSPSC -
39121528

Technical Specification

Type of interface for safety communication -
UN
Rated control supply voltage Us at AC 50HZ -
- Volt
Rated control supply voltage Us at AC 60HZ -
- Volt
Rated control supply voltage Us at DC -
- Volt
Light dot -
- Square millimetre
Min. reflector distance -
- Millimetre
Transmission range of the safety field -
- Metre
Type of safety acc. IEC 61496-1 -
UN
AWG-number -
-
Diameter sensor -
- Millimetre
Max. switching distance -
- Millimetre
Rated switching distance -
- Millimetre
Max. output current -
100 Milliampere
Material housing -
Plastic
Time of reaction -
2 Millisecond
Degree of protection (IP) -
IP67
Thumbnail of product picture -
Adjustment range -
50 Millimetre
Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Explosion safety category for dust -
None
Explosion safety category for gas -
None
Height of sensor -
42.7 Millimetre
Housing material -
Plastic
Laser protection class -
Class 2
Length of sensor -
30 Millimetre
Material of cable sheath -
Polyurethane (PUR)
Material of optical surface -
Plastic
Max. output current at protected output -
0 Milliampere
Maximum output current -
100 Milliampere
Number of contact energized outputs with signalling function -
0
Number of protected contact energized outputs -
0
Number of protected semiconductor outputs -
0
Number of semiconductor outputs with signalling function -
2
Operating distance -
5 Millimetre
Operation agent-safety class -
Safety class 3
Rated control supply voltage at DC -
10 Volt
Reaction time -
0.2 Millisecond
Sensing mode -
Light switching
Setting procedure -
Manual adjustment
Switching frequency -
2500 Hertz
Switching voltage of OSSD at state "high" -
0 Volt
Triangulation -
Background fade-out
Type of electric connection -
Cable
Type of light -
Laser diode, red light
Type of switch function -
Other
Type of switching output -
NPN
Voltage type -
DC
Wavelength of the sensor -
650 Nanometre
Width sensor -
15 Millimetre
