3067381

LT3 Series: Laser Retroreflective TimeofFlight S; Range: 500 mm to 50 m; 1224 V dc ; Outputs: Discrete: 2 PNP or NPN; Euro 8pin Qu

Manufacturer's No: LT3BDLVQ
LT3 Series: Laser Retroreflective TimeofFlight S; Range: 500 mm to 50 m; 1224 V dc ; Outputs: Discrete: 2 PNP or NPN; Euro 8pin QuickDisconnect;

Availability Back Order

£1,742.01
  • LT3 Series: Laser Retroreflective Time-of-Flight Sensor
  • Range: 500 mm to 50 m
  • Supply Voltage: 12-24 V DC
  • Outputs: 2 PNP or NPN Discrete
  • Connector: Euro 8-pin Quick Disconnect


Product

Manufacturer Material ID -
LT3BDLVQ
Net Weight -

Additional Product Information

UNSPSC -
39122216

Technical Specification

Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
68.5 Millimetre
Housing material -
Plastic
Laser protection class -
Class 1
Length of sensor -
87 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Setting procedure -
Teach-In
Supply voltage -
12 Volt
Switching frequency -
1000 Hertz
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Width sensor -
35.3 Millimetre


Availability Back Order

£1,742.01
