3801130

Laser Diffuse Time-of-Flight Sensor, Range: 50-12000, Input: 12-30 V dc, Output 1: NPN/PNP Configurable, IO-Link, Output 2: NPN/PN

Manufacturer's No: LTF12KC2LDQ     Manufacturer: Turck Banner
Laser Diffuse Time-of-Flight Sensor, Range: 50-12000, Input: 12-30 V dc, Output 1: NPN/PNP Configurable, IO-Link, Output 2: NPN/PNP Configurable, Class 2 Laser, M12 Integral QD

Availability On Request

POA
  • Photoelectric Sensor with Diffuse-Mode Laser (Runtime Measurement)
  • Operating Voltage: 12-30 VDC
  • Max. Range: 12000 mm
  • 2-line, 8-segment Display
  • M12 × 1 Male Connector, Rotatable, 5-pin
  • Range: 0.05-12 m
  • Laser Class 2, Red, 660 nm
  • Resolution: 0.3-3 mm
  • Output 1: PNP Switching Output with IO-Link Communication
  • Output 2: PNP Switching Output, Alarm Output, or Pulse Frequency Modulation (PFM)

Read more

  • Transmission of Process Value and Parametrization via IO-Link


Product

Manufacturer Material ID -
LTF12KC2LDQ
Net Weight -
0.39kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39121527

Technical Specification

Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
56 Millimetre
Housing material -
Other
Laser protection class -
Class 2
Length of sensor -
77 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Standard for interfaces -
Other
Supply voltage -
12 Volt
Switching frequency -
250 Hertz
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Width sensor -
26 Millimetre
