3051279

M12 Laser: Class 2 Emitter, Range: refer to datasheet, Input: 10-30 V dc, Output: Not Applicable, 2 m (6.5 ft) Cable

Manufacturer's No: M126E2LD     Manufacturer: Turck Banner
M12 Laser: Class 2 Emitter, Range: refer to datasheet, Input: 10-30 V dc, Output: Not Applicable, 2 m (6.5 ft) Cable

Availability On Request

POA
  • Type: Photoelectric Sensor (Opposed Mode, Laser Emitter)
  • Operating Voltage: 10-30 VDC
  • Max. Range: 30000 mm
  • Cable Length: 2 m, PVC, 3-wire
  • Protection Class: IP67
  • Housing Material: Aluminum
  • LED Indicator: All-round visible
  • Laser Class: 2


Product

Manufacturer Material ID -
M126E2LD
Net Weight -
0.08kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Degree of protection (IP rating) -
IP67
Diameter sensor -
12 Millimetre
Housing material -
Metal
Laser protection class -
Class 2
Length of sensor -
57 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
30000 Millimetre
Rated switching distance -
30000 Millimetre
Setting procedure -
Other
Type of electric connection -
Cable
Type of light -
Polarity free red light
Wavelength of the sensor -
650 Nanometre
Turck Banner

Availability On Request

POA
