53801 {B}

M12 Laser: Class 2 Emitter, Range: refer to datasheet, Input: 10-30 V dc, Output: Not Applicable, 150 (6 in) M8 Pigtail QD

Manufacturer's No: M126E2LDQ     Manufacturer: Turck Banner
M12 Laser: Class 2 Emitter, Range: refer to datasheet, Input: 10-30 V dc, Output: Not Applicable, 150 (6 in) M8 Pigtail QD

Availability Available to order

£316.29
  • Photoelectric Sensor, Opposed Mode Sensor (Laser Emitter)
  • Max. range: 30000 mm
  • Operating voltage: 10-30 VDC
  • Cable length: 0.15 m, 4-pin, PVC
  • Protection class: IP67
  • Aluminum housing
  • LED all-round visible
  • Laser class 2


Product

Manufacturer Material ID -
M126E2LDQ
Net Weight -
0.06kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Degree of protection (IP rating) -
IP67
Diameter sensor -
12 Millimetre
Housing material -
Metal
Laser protection class -
Class 2
Length of sensor -
57 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
30000 Millimetre
Rated switching distance -
30000 Millimetre
Setting procedure -
Other
Type of electric connection -
Connector M8
Type of light -
Polarity free red light
Wavelength of the sensor -
650 Nanometre
Turck Banner

Availability Available to order

£316.29
