3079746

M25U Series Ultrasonic Receiver, Range: 500 (Normal Speed), 250 (High Speed), Input: 10-30 V dc, Rating: IP69K, Output: Bipolar (1

Manufacturer's No: M25URBQ8     Manufacturer: Turck Banner
M25U Series Ultrasonic Receiver, Range: 500 (Normal Speed), 250 (High Speed), Input: 10-30 V dc, Rating: IP69K, Output: Bipolar (1 NPN & 1 PNP), 5-pin M12 QD

Availability On Request

£729.52
  • Ultrasonic sensor with switching output
  • Operating voltage: 10-30 VDC
  • Max. range: 500 mm
  • Sonic transducer face and sleeve made of V4A 1.4401 (AISI 316)
  • Protection class: IP68/IP69K
  • Housing cover made of polysulphone
  • Max. range: 50 cm
  • Suitable for 200,000 cleaning cycles with water at 85°C for 15 min
  • Operating voltage: 10-30 VDC
  • Switching output: PNP/NPN, NO contact

Read more

  • M12 × 1 male, 5-pin connector
  • Programmable high and low sensitivity


Product

Manufacturer Material ID -
M25URBQ8
Net Weight -
0.14kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Diameter sensor -
25 Millimetre
Housing material -
Other
Length of sensor -
106 Millimetre
Material active area of sensor -
Metal
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
35 Milliampere
Supply voltage -
10 Volt
Type of electric connection -
Plug-in connection
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Turck Banner

Availability On Request

£729.52
