3072506

MAR7216NX485Q 16CH 2-STICK MA RECEIVER

Manufacturer's No: MAR7216NX485Q     Manufacturer: Turck Banner
MAR7216NX485Q 16CH 2-STICK MA RECEIVER

Availability On Request

£1,671.36
  • Measuring light screen with a max. range of 13500 mm
  • Operating voltage: 16-30 VDC
  • Cable length: 0.15 m with a 150 mm cable and male connector (M12 x 1, 8-pin)
  • Scan field (Y): 1819 mm
  • Resolution: 19 mm
  • Range: 13.5 m
  • 2 reversible switching outputs (NPN/PNP)
  • RS485 interface


Product

Manufacturer Material ID -
MAR7216NX485Q
Net Weight -
3.22kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
CN
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Height of sensor -
1908 Millimetre
Length of sensor -
38.1 Millimetre
Reaction time -
54.2 Millisecond
Resolution of the light curtain -
9.5 Millimetre
Safety field height -
1819 Millimetre
Type of electric connection -
Connector M12
Type of switching output of the OSSD -
PNP/NPN
Width sensor -
38.1 Millimetre
Turck Banner

Availability On Request

£1,671.36
