3038025

MINI-BEAM NAMUR: Polarized Retro, Range: 50 - 2 m, Input: 5-15 V dc, Output: NAMUR, 9 m (30 ft) Cable

Manufacturer's No: MIAD9LVAG W/30'     Manufacturer: Turck Banner
MINI-BEAM NAMUR: Polarized Retro, Range: 50 - 2 m, Input: 5-15 V dc, Output: NAMUR, 9 m (30 ft) Cable

Availability On Request

£236.82
  • Photoelectric Sensor, Retroreflective Sensor with Polarizing Filter
  • Operating Voltage: 5-15 VDC
  • Max. Range: 2000 mm
  • Cable Length: 9 m, PVC material
  • Protection Class: IP67
  • Sensitivity adjustable via potentiometer
  • Alignment indicator
  • NAMUR output in accordance with DIN 19234 (IEC/EN 60947-5-6)


Product

Manufacturer Material ID -
MIAD9LVAG W/30'
Net Weight -
0.60kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
30.7 Millimetre
Housing material -
Plastic
Length of sensor -
66 Millimetre
Material of optical surface -
Plastic
Max. switching distance -
2000 Millimetre
Rated switching distance -
2000 Millimetre
Reaction time -
5 Millisecond
Sensing mode -
Light switching
Setting procedure -
Other
Switching frequency -
100 Hertz
Type of electric connection -
Cable
Type of light -
Polarized red light
Type of switch function -
Other
Type of switching output -
NAMUR
Wavelength of the sensor -
650 Nanometre
Width sensor -
12.3 Millimetre
Turck Banner

Availability On Request

£236.82
