3040144

MINI-BEAM NAMUR: Receiver, Range: 6 m, Input: 5-15 V dc, Output: NAMUR, 2 m (6.5 ft) Cable

Manufacturer's No: MIAD9R     Manufacturer: Turck Banner
MINI-BEAM NAMUR: Receiver, Range: 6 m, Input: 5-15 V dc, Output: NAMUR, 2 m (6.5 ft) Cable

Availability On Request

POA
  • Type: Photoelectric Sensor, Opposed Mode (Emitter/Receiver)
  • Operating Voltage: 5-15 VDC
  • Max. Range: 6000 mm
  • Cable Length: 2 m, PVC
  • Protection Class: IP67
  • Sensitivity: Adjustable via potentiometer
  • Alignment Indicator
  • NAMUR Output in accordance with DIN 19234 (IEC/EN 60947-5-6)
  • ATEX Category: II 1 G, Ex Zone 0


Product

Manufacturer Material ID -
MIAD9R
Net Weight -
0.16kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
30.7 Millimetre
Housing material -
Plastic
Length of sensor -
66 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
6000 Millimetre
Min. reflector distance -
0 Millimetre
Rated switching distance -
6000 Millimetre
Reaction time -
2 Millisecond
Sensing mode -
Light switching
Setting procedure -
Other
Switching frequency -
100 Hertz
Type of electric connection -
Cable
Type of switch function -
Other
Type of switching output -
NAMUR
Width sensor -
12.3 Millimetre
Turck Banner

Availability On Request

POA
