4611230

Inductive Sensor, With Increased Temperature Range

Manufacturer's No: NI8-M18-AP6X/S120     Manufacturer: Turck Banner
Inductive Sensor, With Increased Temperature Range

Availability On Request

POA
  • Inductive sensor
  • Operating voltage: 10-30 VDC
  • Rated switching distance: 8 mm
  • Temperature range: Up to +120°C
  • Non-flush design
  • Threaded barrel: M18 x 1, made of chrome-plated brass
  • DC 3-wire
  • Normally open (NO) contact
  • PNP output
  • Cable length: 2 m


Product

Manufacturer Material ID -
NI8-M18-AP6X/S120
Net Weight -
0.16kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Coating housing -
Chrome plated
Construction type housing -
Cylinder, screw-thread
Diameter sensor -
18 Millimetre
Housing material -
Metal
Length of sensor -
97 Millimetre
Mechanical mounting condition for sensor -
Not flat
Supply voltage -
10 Volt
Switching distance -
8 Millimetre
Switching frequency -
100 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Cable
Type of switch function -
Normally open contact
Type of switching output -
PNP
Voltage type -
DC
