4012151

Inductive Sensor, With Increased Temperature Range

Manufacturer's No: NI10-EM18WDTC-Y1X     Manufacturer: Turck Banner
Inductive Sensor, With Increased Temperature Range

Availability On Request

£150.96
  • Inductive sensor with increased temperature range
  • Rated switching distance: 10 mm
  • Non-flush, threaded barrel: M18 x 1, stainless steel 1.4404
  • Temperature range: -40 °C to +100 °C
  • High protection class IP69K for harsh environments
  • Special double-lip seal for protection against acidic and alkaline cleaning agents
  • Suitable for food industry applications
  • DC 2-wire, nominal 8.2 VDC
  • Output according to DIN EN 60947-5-6 (NAMUR)
  • Terminal chamber

Read more

  • ATEX category II 1 G, Ex Zone 0 up to +80 °C
  • ATEX category II 2 G, Ex Zone 1
  • ATEX category II 1 D, Ex Zone 20 for temperatures from -25 °C to +70 °C
  • SIL 2 (Low Demand Mode) according to IEC 61508, PL c according to ISO 13849-1 at HFT0
  • SIL 3 (All Demand Mode) according to IEC 61508, PL e according to ISO 13849-1 with redundant configuration HTF1


Product

Manufacturer Material ID -
NI10-EM18WDTC-Y1X
Net Weight -
0.09kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Construction type housing -
Cylinder, screw-thread
Diameter sensor -
18 Millimetre
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 1G
Housing material -
Metal
Length of sensor -
71 Millimetre
Mechanical mounting condition for sensor -
Not flat
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
None
Suitable for safety functions -
Switching distance -
10 Millimetre
Switching frequency -
500 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Clamp
Type of switching output -
NAMUR
Voltage type -
DC
