1004700 {T}

Inductive Sensor, Operating voltage Nom. 8.2 VDC, Rated switching distance

Manufacturer's No: NI3-EH6.5K-Y1     Manufacturer: Turck Banner
Inductive Sensor, Operating voltage Nom. 8.2 VDC, Rated switching distance

Availability Available to order

£58.46
  • Inductive Sensor
  • Rated switching distance: 3 mm
  • Non-flush design
  • Smooth barrel Ø 6.5 mm made of stainless steel (1.4427 SO)
  • Cable length: 2 m
  • DC 2-wire, nominal voltage: 8.2 VDC
  • Output according to DIN EN 60947-5-6 (NAMUR)
  • Cable connection
  • ATEX category II 1 G, Ex zone 0
  • ATEX category II 1 D, Ex zone 20

Read more

  • SIL2 (Low Demand Mode) according to IEC 61508, PL c according to ISO 13849-1 with HFT0
  • SIL3 (All Demand Mode) according to IEC 61508, PL e according to ISO 13849-1 with redundant configuration HFT1


Product

Manufacturer Material ID -
NI3-EH6.5K-Y1
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
CH
UNSPSC -
39122216

Technical Specification

Construction type housing -
Cylinder plain
Diameter sensor -
6.5 Millimetre
Explosion safety category for dust -
ATEX dust-ex-protection, Cat. 1D
Explosion safety category for gas -
ATEX gas-ex-protection, Cat. 1G
Housing material -
Metal
Length of sensor -
23.6 Millimetre
Mechanical mounting condition for sensor -
Not flat
Performance level acc. to EN ISO 13849-1 -
Level c
SIL according to IEC 61508 -
None
Suitable for safety functions -
Switching distance -
3 Millimetre
Switching frequency -
5000 Hertz
Type of actuation -
Metallic Target
Type of electric connection -
Cable
Type of switching output -
NAMUR
Voltage type -
DC
Turck Banner

Availability Available to order

£58.46
