3077766

WORLDBEAM Q20 Series: Retro; Range: 6 m; Input 1030V dc; Output: Complementery Solid State PNP; Integral PicoStyle QuickDisconnect

Manufacturer's No: Q20PLVQ7
WORLDBEAM Q20 Series: Retro; Range: 6 m; Input 1030V dc; Output: Complementery Solid State PNP; Integral PicoStyle QuickDisconnect Connector;

Availability Back Order

£116.67
  • Model: WORLDBEAM Q20 Series (Retro)
  • Range: 6 meters
  • Input: 10-30V DC
  • Output: Complementary Solid State PNP
  • Connector: Integral PicoStyle QuickDisconnect


Product

Manufacturer Material ID -
Q20PLVQ7
Net Weight -

Additional Product Information

UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
42 Millimetre
Housing material -
Plastic
Length of sensor -
20 Millimetre
Material of optical surface -
Plastic
Max. switching distance -
6000 Millimetre
Rated switching distance -
6000 Millimetre
Reaction time -
0.8 Millisecond
Switching frequency -
600 Hertz
Type of electric connection -
Connector M8
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Wavelength of the sensor -
645 Nanometre
Width sensor -
12 Millimetre


Availability Back Order

£116.67
