Q45 Series: Polarized Retro, Range: 0.15 to 6 m, Input: 12-250 V dc / 24-250 V ac, Output: SPST Solid-State Relay, 4-pin Mini Inte

Manufacturer's No: Q45BW13LPQ     Manufacturer: Turck Banner
Q45 Series: Polarized Retro, Range: 0.15 to 6 m, Input: 12-250 V dc / 24-250 V ac, Output: SPST Solid-State Relay, 4-pin Mini Integral QD

Availability On Request

£184.19
  • Type: Photoelectric Sensor, Retroreflective Sensor with Polarizing Filter
  • Operating Voltage: 24-250 VAC / 12-250 VDC
  • Maximum Range: 6000 mm
  • Connector: Male connector 7/8"
  • Protection Class: IP67
  • Sensitivity Adjustment: Via potentiometer
  • Output: Relay output, NO (SPST)
  • Operation Mode: Light or dark operation, adjusted via selector switch


Product

Manufacturer Material ID -
Q45BW13LPQ
Net Weight -
0.27kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-25 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
30 Millimetre
Height of sensor -
101.6 Millimetre
Housing material -
Plastic
Length of sensor -
56.4 Millimetre
Material of optical surface -
Plastic
Max. switching distance -
6000 Millimetre
Rated switching distance -
6000 Millimetre
Reaction time -
2 Millisecond
Reflector included -
Switching frequency -
33 Hertz
Type of electric connection -
Connector 7/8 inch
Type of light -
Polarized red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
Relay contact
Wavelength of the sensor -
680 Nanometre
Width sensor -
44.5 Millimetre
Turck Banner

Availability On Request

£184.19
