Analog Q45U Series: Proximity Mode, Range: 100 - 1.4 m, Input: 15-24 V dc, Output: Selectable 0-10 V dc or 4-20 mA sourcing, Mini-

Manufacturer's No: Q45ULIU64ACRQ     Manufacturer: Turck Banner
Analog Q45U Series: Proximity Mode, Range: 100 - 1.4 m, Input: 15-24 V dc, Output: Selectable 0-10 V dc or 4-20 mA sourcing, Mini-Style Integral QD

Availability On Request

POA
  • Ultrasonic sensor in diffuse mode
  • Operating voltage: 12-24 VDC
  • Max. range: 1400 mm
  • Measuring range adjustable via teach button or control line
  • Response time adjustable
  • Analog output for voltage or current
  • Teach-in function for easy setup
  • Convertible output curves for flexibility
  • Aperture angle of sonic cone: 15°
  • Blind zone: 10 cm

Read more

  • Range: 140 cm


Product

Manufacturer Material ID -
Q45ULIU64ACRQ
Net Weight -
0.27kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-25 Degrees celsius
Construction type housing -
Cuboid
Height of sensor -
102.6 Millimetre
Housing material -
Plastic
Length of sensor -
60.5 Millimetre
Material active area of sensor -
Plastic
Material of cable sheath -
Polyvinyl chloride (PVC)
Measuring range length -
100 Millimetre
Supply voltage -
12 Volt
Type of analogy output -
4 mA ... 20 mA
Type of electric connection -
Plug-in connection
Type of switching output -
Other
Width sensor -
44.5 Millimetre
