3097542

Q4X Series: Laser Adjustable Field, Range: 110, Input 12-30 V dc, Output: Analog: 4-20 mA, 5-pin M12 Integral QD, Flush Mount Hous

Manufacturer's No: Q4XFILAF110-Q8     Manufacturer: Turck Banner
Q4X Series: Laser Adjustable Field, Range: 110, Input 12-30 V dc, Output: Analog: 4-20 mA, 5-pin M12 Integral QD, Flush Mount Housing

Availability On Request

£544.42
  • Photoelectric Sensor with Laser Distance Sensor (Triangulation)
  • Analog Output: 4-20 mA
  • Operating Voltage: 12-30 VDC
  • Max. Range: 110 mm
  • Range: 35-110 mm
  • Laser Class 1, 655 nm
  • IP67/69K Rated
  • ECOLAB-Certified
  • Stainless Steel Housing (1.4404)
  • 4-Digit 7-Segment LED Display

Read more

  • Output Indicator (Yellow)
  • Rectangular Design
  • 3 Buttons


Product

Manufacturer Material ID -
Q4XFILAF110-Q8
Net Weight -
0.15kg

Additional Product Information

Commodity Code -
90314990000
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
57.5 Millimetre
Housing material -
Other
Laser protection class -
Class 1
Length of sensor -
33.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Other
Supply voltage -
10 Volt
Type of analogy output -
4 mA ... 20 mA
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switching output -
Other
Width sensor -
18 Millimetre
Turck Banner

Availability On Request

£544.42
