3070092

Q60 Series: Adjustable-Field Visible Red, Range: 200-1000, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, 2 m (6.5 ft) Cable

Manufacturer's No: Q60BB6AFV1000     Manufacturer: Turck Banner
Q60 Series: Adjustable-Field Visible Red, Range: 200-1000, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, 2 m (6.5 ft) Cable

Availability On Request

£233.19
  • Photoelectric Sensor in Diffuse Mode
  • Adjustable Background Suppression
  • Operating Voltage: 10-30 VDC
  • Max. Range: 1000 mm
  • Cable Length: 2 m, PVC material
  • Protection Class: IP67
  • 5-Segment LED Display for Signal Indication
  • Keylock feature
  • Switch ON/OFF Delay: Adjustable between 8-16 ms
  • Switching Output: Bipolar

Read more

  • Light or Dark Operation


Product

Manufacturer Material ID -
Q60BB6AFV1000
Net Weight -
0.22kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Adjustment range -
200 Millimetre
Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
75 Millimetre
Housing material -
Plastic
Length of sensor -
60 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
1000 Millimetre
Rated switching distance -
1000 Millimetre
Reaction time -
2 Millisecond
Switching frequency -
250 Hertz
Type of electric connection -
Cable
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Wavelength of the sensor -
640 Nanometre
Width sensor -
25 Millimetre
Turck Banner

Availability On Request

£233.19
