3063005

Q60 Series: Adjustable-Field Infrared Univrs Volt, Range: 200-2000, Input: 12-250 V dc or 24-250 V ac, Output: Electromechanical R

Manufacturer's No: Q60VR3AF2000Q1     Manufacturer: Turck Banner
Q60 Series: Adjustable-Field Infrared Univrs Volt, Range: 200-2000, Input: 12-250 V dc or 24-250 V ac, Output: Electromechanical Relay (SPST), Micro-Style QD

Availability On Request

£264.04
  • Photoelectric Sensor in Diffuse Mode
  • Adjustable Background Suppression
  • Operating Voltage: 24-250 VAC / 12-250 VDC
  • Max. Range: 2000 mm
  • Male 1/2" 4-pin connector, rotatable by 90°
  • Protection Class: IP67
  • 5-segment LED Display for Signal Indication
  • Keylock feature
  • Switch ON/OFF delay adjustable between 8-16 ms
  • Relay Output


Product

Manufacturer Material ID -
Q60VR3AF2000Q1
Net Weight -
0.13kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Adjustment range -
200 Millimetre
Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
75 Millimetre
Housing material -
Plastic
Length of sensor -
60 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
2000 Millimetre
Rated switching distance -
2000 Millimetre
Reaction time -
15 Millisecond
Switching frequency -
33 Hertz
Type of electric connection -
Connector 1/2 inch
Type of light -
Infrared light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
Relay contact
Wavelength of the sensor -
880 Nanometre
Width sensor -
25 Millimetre
