44331 {B}

QM42 Series: Emitter, Range: 10 m, Input: 10-30 V dc, Output: Not Applicable, 2 m (6.5 ft) Cable

Manufacturer's No: QM426E     Manufacturer: Turck Banner
QM42 Series: Emitter, Range: 10 m, Input: 10-30 V dc, Output: Not Applicable, 2 m (6.5 ft) Cable

Availability Available to order

£197.53
  • Photoelectric Sensor, Opposed Mode Sensor (Emitter)
  • Operating voltage: 10-30 VDC
  • Max. range: 10000 mm
  • Cable length: 2 m, 4-wire, PVC
  • Metal housing, ZN, black
  • Protection class: IP67


Product

Manufacturer Material ID -
QM426E
Net Weight -
0.19kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
42 Millimetre
Housing material -
Metal
Length of sensor -
42 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
10000 Millimetre
Rated switching distance -
10000 Millimetre
Type of electric connection -
Cable
Type of light -
Infrared light
Wavelength of the sensor -
880 Nanometre
Width sensor -
12.7 Millimetre
Turck Banner

Availability Available to order

£197.53
