QM42 Series: Emitter, Range: 10 m, Input: 10-30 V dc, Output: Not Applicable, 4-pin M12 Integral QD

Manufacturer's No: QM426EQ     Manufacturer: Turck Banner
QM42 Series: Emitter, Range: 10 m, Input: 10-30 V dc, Output: Not Applicable, 4-pin M12 Integral QD

Availability On Request

£174.21
  • Type: Photoelectric Sensor, Opposed Mode (Emitter)
  • Operating Voltage: 10-30 VDC
  • Maximum Range: 10000 mm
  • Connector: Male M12 × 1, 4-pin
  • Housing Material: Metal (ZN, black)
  • Protection Class: IP67


Product

Manufacturer Material ID -
QM426EQ
Net Weight -
0.10kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
60.2 Millimetre
Housing material -
Metal
Length of sensor -
42 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
10000 Millimetre
Rated switching distance -
10000 Millimetre
Type of electric connection -
Connector M12
Type of light -
Infrared light
Wavelength of the sensor -
880 Nanometre
Width sensor -
12.7 Millimetre
Turck Banner

Availability On Request

£174.21
