3045785

Photoelectric Sensor, Photoelectric Sensor for Plastic Fibers

Manufacturer's No: QM42VN6FP     Manufacturer: Turck Banner
Photoelectric Sensor, Photoelectric Sensor for Plastic Fibers

Availability On Request

POA
  • Photoelectric sensor for plastic fibers
  • Operating voltage: 10-30 VDC
  • Cable length: 2 meters, PVC material, 4-wire
  • Metal housing with black ZN coating
  • Protection class: IP67
  • Sensitivity adjustment via potentiometer
  • NPN switching output
  • Light/dark operation


Product

Manufacturer Material ID -
QM42VN6FP
Net Weight -
0.20kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
42 Millimetre
Housing material -
Other
Length amplifier -
48.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
30 Milliampere
Type of electric connection -
Cable
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
NPN
Width amplifier -
12.7 Millimetre
Turck Banner

Availability On Request

POA
