QM42 Series: Plastic Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: SPDT (Complementary) PNP, 4-pin M12 Integral

Manufacturer's No: QM42VP6FPQ     Manufacturer: Turck Banner
QM42 Series: Plastic Fiber Optic, Range: Depends on Fiber, Input: 10-30 V dc, Output: SPDT (Complementary) PNP, 4-pin M12 Integral QD

Availability Available to order

£233.68
  • Photoelectric sensor for plastic fibers
  • Operating voltage: 10-30 VDC
  • Male M12 x 1, 4-pin
  • Metal housing, ZN, black
  • Protection class: IP67
  • Sensitivity adjusted via potentiometer
  • PNP switching output
  • Light/dark operation


Product

Manufacturer Material ID -
QM42VP6FPQ
Net Weight -
0.10kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height amplifier -
60.2 Millimetre
Housing material -
Other
Length amplifier -
48.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
No load current -
30 Milliampere
Type of electric connection -
Connector M12
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Width amplifier -
12.7 Millimetre
Turck Banner

Availability Available to order

£233.68
