Vibration & Temperature Sensor, With Serial Interface, Modbus RTU

Manufacturer's No: QM42VT2     Manufacturer: Turck Banner
Vibration & Temperature Sensor, With Serial Interface, Modbus RTU

Availability On Request

POA
  • Vibration & Temperature Sensor with Serial Interface
  • Operating Voltage: 10-24 VDC or 3.6-5.5 VDC
  • Temperature Measuring Range: -40 to 105°C, Resolution: 1°C, Accuracy: ±3°C
  • Vibration Measuring Range: 0 to 65 mm/s RMS, Frequency Range: 10 to 1000 Hz, Accuracy: ±10% at 25°C
  • Sturdy zinc case with IP67 protection class
  • Cable Length: 3m, PVC cable with M12 × 1 male connector, 5-pin
  • Shock Resistant up to 400g
  • RS485 Interface, Modbus RTU supported
  • BWA-BK-005 Mounting Plate Kit included

Follow-up article



Product

Manufacturer Material ID -
QM42VT2
Net Weight -
0.34kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216
