Vibration & Temperature Sensor, Synchronous Serial Interface, Modbus RTU

Manufacturer's No: QM42VT2QP     Manufacturer: Turck Banner
Vibration & Temperature Sensor, Synchronous Serial Interface, Modbus RTU

Availability On Request

POA
  • Vibration & Temperature Sensor with Modbus RTU interface
  • Operating voltage: 10-24 VDC or 3.6-5.5 VDC
  • Temperature measuring range: -40 to 105°C, Resolution: 1°C, Accuracy: ±3°C
  • Vibration measuring range: 0 to 65 mm/s RMS, Frequency range: 10 to 1000 Hz, Accuracy: ±10% at 25°C
  • Sturdy zinc case with IP67 protection class
  • Shock resistant up to 400g
  • Synchronous Serial Interface: RS485
  • Cable: M12 x 1 with male end, PVC, 150 mm, 5-pin
  • Cable length: 0.15 m
  • BWA-BK-005 mounting plate kit included

Follow-up article



Product

Manufacturer Material ID -
QM42VT2QP
Net Weight -
0.19kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
43211902
