3056897

QMT42 Series: Long Range Diffuse, Range: 10 to 6 m, Input: 10-30 V dc, Output: SPDT (Complementary) PNP, 4-pin M12 Integral QD

Manufacturer's No: QMT42VP6DXQ     Manufacturer: Turck Banner
QMT42 Series: Long Range Diffuse, Range: 10 to 6 m, Input: 10-30 V dc, Output: SPDT (Complementary) PNP, 4-pin M12 Integral QD

Availability On Request

POA
  • Photoelectric Sensor
  • Diffuse Mode Sensor
  • Operating Voltage: 10-30 VDC
  • Maximum Range: 6000 mm
  • Male M12 × 1, 4-pin
  • Metal Housing (ZN, black)
  • Protection Class: IP67
  • Sensitivity Adjustment via Potentiometer
  • PNP Switching Output
  • Light/Dark Operation


Product

Manufacturer Material ID -
QMT42VP6DXQ
Net Weight -
0.14kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
Minimum Order Quantity -
1
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Height of sensor -
76.2 Millimetre
Housing material -
Metal
Length of sensor -
42 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
6000 Millimetre
Reaction time -
1 Millisecond
Switching frequency -
500 Hertz
Type of electric connection -
Connector M12
Type of light -
Infrared light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
PNP
Wavelength of the sensor -
880 Nanometre
Width sensor -
18 Millimetre
