3075227

WORLD-BEAM QS18 Expert Series, Diffuse, Range: 600, Input: 10-30 V dc, Output: PNP, M8 4-pim Integral QD

Manufacturer's No: QS18EP6DVQ7     Manufacturer: Turck Banner
WORLD-BEAM QS18 Expert Series, Diffuse, Range: 600, Input: 10-30 V dc, Output: PNP, M8 4-pim Integral QD

Availability On Request

£87.11
  • Photoelectric Sensor
  • Diffuse Mode Sensor
  • Operating Voltage: 10-30 VDC
  • Max. Range: 600 mm
  • Male M8 x 1, 4-pin
  • Protection Class: IP67
  • LED all-round visible
  • Sensitivity adjusted via teach button
  • PNP switching output
  • Light or dark operation


Product

Manufacturer Material ID -
QS18EP6DVQ7
Net Weight -
0.05kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
35 Millimetre
Housing material -
Plastic
Length of sensor -
31 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
600 Millimetre
Reaction time -
0.6 Millisecond
Switching frequency -
833 Hertz
Type of electric connection -
Connector M8
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP
Wavelength of the sensor -
630 Nanometre
Width sensor -
15 Millimetre
Turck Banner

Availability On Request

£87.11
