3073238

WORLD-BEAM QS18 LASER POLAR RETRO, Range: 0.1-10 m, Input: 10-30 V dc, Output: Complementary Solid-State NPN, 150 M12 Pigtail QD

Manufacturer's No: QS18VN6LLPQ5     Manufacturer: Turck Banner
WORLD-BEAM QS18 LASER POLAR RETRO, Range: 0.1-10 m, Input: 10-30 V dc, Output: Complementary Solid-State NPN, 150 M12 Pigtail QD

Availability On Request

£187.82
  • Photoelectric Sensor, Retroreflective Laser Sensor with Polarizing Filter
  • Operating Voltage: 10-30 VDC
  • Max. Range: 10,000 mm
  • Cable Length: 0.15 m, M12 × 1, 4-pin, PVC
  • Protection Class: IP67
  • LED, All-round visible
  • Sensitivity adjusted via potentiometer
  • Recommended reflectors: Microprism reflector BRT-51X51BM for ranges up to 10 m, self-adhesive reflector film BRT-TVHG-2X2 for ranges up to 1.5 m (included)
  • NPN switching output, changeover


Product

Manufacturer Material ID -
QS18VN6LLPQ5
Net Weight -
0.08kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-10 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
35 Millimetre
Housing material -
Plastic
Laser protection class -
Class 1
Length of sensor -
31 Millimetre
Material of optical surface -
Plastic
Max. switching distance -
10000 Millimetre
Rated switching distance -
10000 Millimetre
Reaction time -
0.7 Millisecond
Reflector included -
Setting procedure -
Other
Switching frequency -
700 Hertz
Type of electric connection -
Connector M12
Type of light -
Polarized red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
NPN
Wavelength of the sensor -
650 Nanometre
Width sensor -
15 Millimetre
Turck Banner

Availability On Request

£187.82
