3083301

WORLD-BEAM QS30 Series: H2O SHP Receiver, Range: 8 m, Input: 10-30 V dc, Output: LO, Bipolar: 1 NPN, 1 PNP, 2 m (6.5 ft) Cable

Manufacturer's No: QS30ARXSH2O     Manufacturer: Turck Banner
WORLD-BEAM QS30 Series: H2O SHP Receiver, Range: 8 m, Input: 10-30 V dc, Output: LO, Bipolar: 1 NPN, 1 PNP, 2 m (6.5 ft) Cable

Availability On Request

£242.27
  • Type: Photoelectric Sensor (Opposed Mode - Emitter/Receiver)
  • Application: Water Detection
  • Operating Voltage: 10-30 VDC
  • Max. Detection Range: 8000 mm
  • Cable Length: 2 m, PVC
  • Protection Class: IP67
  • LED Indicator: All-round visible
  • Selectable Operating Frequency
  • Crosstalk Protection
  • Switching Output: Bipolar, Light Operation


Product

Manufacturer Material ID -
QS30ARXSH2O
Net Weight -
0.15kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
30 Millimetre
Height of sensor -
53 Millimetre
Housing material -
Plastic
Length of sensor -
54.3 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
8000 Millimetre
Rated switching distance -
8000 Millimetre
Reaction time -
10 Millisecond
Sensing mode -
Light switching
Setting procedure -
Other
Type of electric connection -
Cable
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Width sensor -
22 Millimetre
Turck Banner

Availability On Request

£242.27
