3083306

WORLD-BEAM QS30 Series: H2O SHP Receiver, Range: 8 m, Input: 10-30 V dc, Output: DO, Bipolar: 1 NPN, 1 PNP, 150 (6 in) 5-pin M12 P

Manufacturer's No: QS30RRXSH2OQ5     Manufacturer: Turck Banner
WORLD-BEAM QS30 Series: H2O SHP Receiver, Range: 8 m, Input: 10-30 V dc, Output: DO, Bipolar: 1 NPN, 1 PNP, 150 (6 in) 5-pin M12 Pigtail QD

Availability On Request

£259.50
  • Type: Photoelectric Sensor (Opposed Mode - Emitter/Receiver)
  • Application: Water Detection
  • Operating Voltage: 10-30 VDC
  • Max. Detection Range: 8000 mm
  • Cable Length: 0.15 m
  • Connector: Male M12 × 1, 5-pin
  • Protection Class: IP67
  • Output: Switching output, bipolar
  • Special Feature: Super high-power water detection sensor
  • Operation: Dark operation


Product

Manufacturer Material ID -
QS30RRXSH2OQ5
Net Weight -
0.11kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
30 Millimetre
Height of sensor -
57 Millimetre
Housing material -
Plastic
Length of sensor -
54.3 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
8000 Millimetre
Rated switching distance -
8000 Millimetre
Reaction time -
10 Millisecond
Sensing mode -
Dark switching
Setting procedure -
Other
Type of electric connection -
Connector M12
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Width sensor -
22 Millimetre
Turck Banner

Availability On Request

£259.50
