WORLD-BEAM QS30 Series: Universal Voltage, Range: 400, Input: 12-250 V dc or 24-250 V ac, Output: SPDT e/m Relay, 2 m (6.5 ft) Cab

Manufacturer's No: QS30VR3FF400     Manufacturer: Turck Banner
WORLD-BEAM QS30 Series: Universal Voltage, Range: 400, Input: 12-250 V dc or 24-250 V ac, Output: SPDT e/m Relay, 2 m (6.5 ft) Cable

Availability On Request

£148.81
  • Type: Photoelectric Sensor, Diffuse Mode with Fixed-Field Background Suppression
  • Operating Voltage: 24-250 VAC / 12-250 VDC
  • Max. Range: 400 mm
  • Cable Length: 2 m, PVC
  • Protection Class: IP67
  • LED Indicator: All-round visible
  • Output: Relay, Changeover


Product

Manufacturer Material ID -
QS30VR3FF400
Net Weight -
0.19kg

Additional Product Information

Commodity Code -
85365080900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Adjustment range -
0 Millimetre
Ambient temperature -
-40 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
30 Millimetre
Height of sensor -
44 Millimetre
Housing material -
Plastic
Length of sensor -
51.5 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
400 Millimetre
Rated switching distance -
400 Millimetre
Reaction time -
15 Millisecond
Switching frequency -
33 Hertz
Type of electric connection -
Cable
Type of light -
Polarity free red light
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
Relay contact
Wavelength of the sensor -
680 Nanometre
Width sensor -
22 Millimetre
