1590854

Miniature Encoder, With Analog Output, Premium Line

Manufacturer's No: RI360P1-QR14-ELIU5X2-0.3-RS5     Manufacturer: Turck Banner
Miniature Encoder, With Analog Output, Premium Line

Availability On Request

£168.52
  • Miniature encoder with analog output
  • Premium line with high-quality features
  • Operating voltage: 15 to 30 VDC
  • Cable length: 0.3 m with male connector, M12 × 1
  • Rectangular plastic design with many mounting options
  • P1-Ri-QR14 included in delivery
  • Measuring range displayed via LED
  • Immune to electromagnetic interference
  • Resolution: 12-bit
  • Programmable measuring range: 0 to 10 V and 4 to 20 mA


Product

Manufacturer Material ID -
RI360P1-QR14-ELIU5X2-0.3-RS5
Net Weight -
0.08kg

Additional Product Information

Commodity Code -
90318020000
Country of Origin -
DE
UNSPSC -
39122216

Technical Specification

Degree of protection (IP rating) -
IP68
Diameter axle -
6 Millimetre
Housing material -
Plastic
Model -
Other
Physical measurement principle -
Inductive
Programmable -
Standard for interfaces -
Analogue
Type of electric connection -
Cable with connector
Type of shaft encoder -
Hollow shaft
Turck Banner

Availability On Request

£168.52
