2CDS282001R0204

S202P-C20 Miniature Circuit Breaker C-Char.,25kA,20A,2P

Manufacturer's No: S202PC20     Manufacturer: ABB
S202P-C20 Miniature Circuit Breaker C-Char.,25kA,20A,2P

Availability Back Order

POA
  • Type: Miniature Circuit Breaker
  • Model: S202P-C20
  • Tripping Mechanisms: Delayed thermal for overload protection, Electromechanic for short circuit protection
  • Characteristics: B, C, D, K, Z
  • Configurations: 1P, 1P+N, 2P, 3P, 3P+N, 4P
  • Breaking Capacity: Up to 25 kA at 230/400 V AC
  • Rated Current: Up to 63A
  • Compliance: IEC/EN 60898-1, IEC/EN 60947-2, UL1077, CSA 22.2 No. 235
  • Suitable for: Residential, commercial, and industrial applications
  • Auxiliary Contact: Bottom-fitting, saves 50% space


Product

Manufacturer Material ID -
S202PC20
Net Weight -
0.28kg

Additional Product Information

Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Built-in depth -
69 Millimetre
Release characteristic -
C
Degree of protection (IP) -
IP20
Voltage type -
AC/DC
Recess depth -
69 Millimetre
Rated current -
20 Ampere
Rated voltage -
400 Volt
Frequency -
50 Hertz
Tripping characteristic (type/curve) -
C
Rated insulation voltage Ui -
440 Volt
Current limiting class -
3
Over voltage category -
3
Pollution degree -
3
Width in number of modular spacings -
2
Degree of protection (IP rating) -
IP20
Number of protected poles -
2
Connectable conductor cross section solid-core -
0.75 Square millimetre
Connectable conductor cross section multi-wired -
0.75 Square millimetre
Ambient temperature during operating -
-25 Degrees celsius
Additional equipment possible -
Number of poles (total) -
2
Rated short-circuit breaking capacity Icn EN 60898 at 400 V -
25 kiloampere
Rated short-circuit breaking capacity Icn EN 60898 at 230 V -
25 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V -
25 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V -
25 kiloampere
Rated impulse-withstand voltage (Uimp) -
4 Kilovolt
