2CDS283103R0971

S203P-D1,6NA Miniature Circuit Breaker D-Char.,15..25kA,1,6A,3P,+NA

Manufacturer's No: S203P-D1,6NA     Manufacturer: ABB
S203P-D1,6NA Miniature Circuit Breaker D-Char.,15..25kA,1,6A,3P,+NA

Availability Back Order

POA
  • Type: Miniature Circuit Breaker
  • Model: S203P-D1,6NA
  • Tripping Mechanisms: Delayed thermal for overload protection, Electromechanic for short circuit protection
  • Characteristics: D-Char.
  • Breaking Capacity: 15-25 kA
  • Rated Current: 1.6A
  • Poles: 3P
  • Configuration: +NA
  • Compliant with: IEC/EN 60898-1, IEC/EN 60947-2, UL1077, CSA 22.2 No. 235
  • Suitable for: Residential, commercial, and industrial applications

Read more

  • Auxiliary Contact: Bottom-fitting, saves 50% space


Product

Manufacturer Material ID -
S203P-D1,6NA
Net Weight -
0.56kg

Additional Product Information

Country of Origin -
DE
Minimum Order Quantity -
1
UNSPSC -
39121601

Technical Specification

Built-in depth -
68 Millimetre
Release characteristic -
D
Degree of protection (IP) -
IP20
Rated short-circuit breaking capacity Icn EN 60898 at 230 V -
12.5 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V -
25 kiloampere
Voltage type -
AC
Recess depth -
69 Millimetre
Rated current -
1.6 Ampere
Rated voltage -
400 Volt
Frequency -
50 Hertz
Tripping characteristic (type/curve) -
D
Rated insulation voltage Ui -
440 Volt
Current limiting class -
3
Over voltage category -
3
Pollution degree -
3
Width in number of modular spacings -
4
Degree of protection (IP rating) -
IP20
Number of protected poles -
3
Concurrently switching N-neutral -
Connectable conductor cross section solid-core -
0.75 Square millimetre
Connectable conductor cross section multi-wired -
0.75 Square millimetre
Ambient temperature during operating -
-25 Degrees celsius
Additional equipment possible -
Number of poles (total) -
4
Rated short-circuit breaking capacity Icn EN 60898 at 400 V -
25 kiloampere
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V -
25 kiloampere
Rated impulse-withstand voltage (Uimp) -
4 Kilovolt
