3014940

SLM Series: Rugged Nickel-Plated Metal Fixed-Distance Slot Sensor, Slot Width: 80, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PN

Manufacturer's No: SLM80B6Q     Manufacturer: Turck Banner
SLM Series: Rugged Nickel-Plated Metal Fixed-Distance Slot Sensor, Slot Width: 80, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, 4-pin M8 Integral QD

Availability Back Order

£171.06
  • SLM Series: Rugged Nickel-Plated Metal Fixed-Distance Slot Sensor
  • Slot Width: 80 mm
  • Input: 10-30 V dc
  • Output: Bipolar with 1 NPN and 1 PNP
  • Connector: 4-pin M8 Integral QD


Product

Manufacturer Material ID -
SLM80B6Q
Net Weight -

Additional Product Information

UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Special construction
Degree of protection (IP rating) -
IP67
Fork width -
80 Millimetre
Height of sensor -
112 Millimetre
Housing material -
Metal
Length of sensor -
80 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
80 Millimetre
Rated switching distance -
80 Millimetre
Reaction time -
0.5 Millisecond
Switching frequency -
1000 Hertz
Type of electric connection -
Connector M8
Type of light -
Polarity free red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Wavelength of the sensor -
680 Nanometre
Width sensor -
12 Millimetre
Turck Banner

Availability Back Order

£171.06
