3072373

EZ-SCREEN Emitter, Resolution: 30, Range: 18 m (60 ft), Defined Area: 1050 (41.3 in), Housing Length: 1120 (44.1 in), Connection:

Manufacturer's No: SLSE30-1050Q8     Manufacturer: Turck Banner
EZ-SCREEN Emitter, Resolution: 30, Range: 18 m (60 ft), Defined Area: 1050 (41.3 in), Housing Length: 1120 (44.1 in), Connection: 8-pin M12 Connector, No test input

Availability Back Order

£1,366.62
  • Light screen for machine safety applications - Emitter with operating voltage: 20-28 VDC - Maximum range: 18000 mm - M12 x 1 male connector, 8-pin - Protection class: IP65 - Adjustments via DIP switch - Resolution: 30 mm - Scan field: 1050 mm - Includes two EZA-MBK-11 mounting brackets - Devices with a length of 900 mm or more also include one EZA-MBK-12 - Personnel safety category 4 - PL e according to EN ISO 13849-1:2008 - Type 4 according to IEC 61496-1, -2 - SIL 3 according to IEC 61508


Product

Manufacturer Material ID -
SLSE30-1050Q8
Net Weight -
0.54kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
MX
UNSPSC -
39122216

Technical Specification

Ambient temperature -
0 Degrees celsius
Fade-out possible -
Height of sensor -
1120 Millimetre
Length of sensor -
45 Millimetre
Reaction time -
21 Millisecond
Resolution of the light curtain -
30 Millimetre
Safety field height -
1050 Millimetre
Suitable for safety functions -
Type of electric connection -
Connector M12
Wavelength of the sensor -
950 Nanometre
Width sensor -
36 Millimetre
With restart blockage -
Turck Banner

Availability Back Order

£1,366.62
