3028905

MINI-BEAM: High Speed Polarized Retro, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, MHS Response Time = 0.3 ms, 2 m (6.5 ft)

Manufacturer's No: SM312LVAGMHS     Manufacturer: Turck Banner
MINI-BEAM: High Speed Polarized Retro, Input: 10-30 V dc, Output: Bipolar: 1 NPN, 1 PNP, MHS Response Time = 0.3 ms, 2 m (6.5 ft) Cable

Availability On Request

£154.25
  • Photoelectric sensor with retroreflective design and polarizing filter
  • Operating voltage: 10-30 VDC
  • Maximum range: 2000 mm
  • Cable length: 2 m, PVC material
  • Protection class: IP67
  • Sensitivity adjustable via potentiometer
  • Alignment indicator for easy setup
  • Switching output: bipolar for light/dark operation


Product

Manufacturer Material ID -
SM312LVAGMHS
Net Weight -
0.16kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
30.7 Millimetre
Housing material -
Plastic
Length of sensor -
53.3 Millimetre
Material of optical surface -
Plastic
Max. switching distance -
2000 Millimetre
Rated switching distance -
2000 Millimetre
Reaction time -
1 Millisecond
Switching frequency -
500 Hertz
Type of electric connection -
Cable
Type of light -
Polarized red light
Type of switch function -
Normally open contact (NO)
Type of switching output -
PNP/NPN
Wavelength of the sensor -
650 Nanometre
Width sensor -
12.3 Millimetre
Turck Banner

Availability On Request

£154.25
