3052576

MINI-BEAM UNIVERSAL: Receiver, Range: 3 m, Input: 24-240 V ac or 24-240 V dc, Output: SPDT Electromechanical Relay, 2 m (6.5 ft) C

Manufacturer's No: SMU31R     Manufacturer: Turck Banner
MINI-BEAM UNIVERSAL: Receiver, Range: 3 m, Input: 24-240 V ac or 24-240 V dc, Output: SPDT Electromechanical Relay, 2 m (6.5 ft) Cable

Availability On Request

£178.75
  • Type: Photoelectric Sensor, Opposed Mode (Emitter/Receiver)
  • Operating Voltage: 24-240 VAC / 24-240 VDC
  • Max. Range: 3000 mm
  • Cable Length: 2 m, PVC
  • Protection Class: IP67
  • Sensitivity: Adjustable via potentiometer
  • Alignment Indicator
  • Relay Output


Product

Manufacturer Material ID -
SMU31R
Net Weight -
0.19kg

Additional Product Information

Commodity Code -
85365019900
Country of Origin -
US
UNSPSC -
39122216

Technical Specification

Ambient temperature -
-20 Degrees celsius
Construction type housing -
Cuboid
Degree of protection (IP rating) -
IP67
Diameter sensor -
18 Millimetre
Height of sensor -
30.7 Millimetre
Housing material -
Plastic
Length of sensor -
81 Millimetre
Material of cable sheath -
Polyvinyl chloride (PVC)
Material of optical surface -
Plastic
Max. switching distance -
3000 Millimetre
Rated switching distance -
3000 Millimetre
Reaction time -
20 Millisecond
Setting procedure -
Other
Switching frequency -
25 Hertz
Type of electric connection -
Cable
Type of switch function -
Change-over contact (NO/NC)
Type of switching output -
Relay contact
Width sensor -
12.3 Millimetre
Turck Banner

Availability On Request

£178.75
