SRN5420K

SR2-SRN5420K Metallic enclosure SR2

Manufacturer's No: SRN5420K     Manufacturer: ABB
SR2-SRN5420K Metallic enclosure SR2

Availability On Request

£185.86
  • Product: SR2-SRN5420K Metallic Enclosure
  • Enclosure Type: SR2
  • Features: Blind door with back plate
  • Dimensions: 500mm x 400mm x 200mm (H x W x D)


Product

Manufacturer Material ID -
SRN5420K
Net Weight -
11.60kg

Additional Product Information

Commodity Code -
85381000
Country of Origin -
IT
Minimum Order Quantity -
1
UNSPSC -
31261502

Technical Specification

Number of conduit inlets -
-
Nominal current (In) -
- Ampere
RAL-number -
7035
Built-in depth -
132 Millimetre
Type of cover -
Door
Material housing -
Steel
Impact strength -
IK10
Degree of protection (IP) -
IP65
Circuit integrity -
None
Colour -
Grey
Cover model -
None
Degree of protection (IP rating) -
IP65
Degree of protection (NEMA) -
3R
Depth -
200 Millimetre
Height -
500 Millimetre
Housing material -
Steel
Impact resistance (IK rating) -
IK10
Internal depth -
183.5 Millimetre
Mounting method -
Surface mounted
Number of modules -
18
Number of openings for flange plates -
2
Number of rows -
2
Plate thickness cabinet -
1.2 Millimetre
Plate thickness door/cover -
1.2 Millimetre
Protection class -
I
RAL number -
7035
Recess depth -
132 Millimetre
Surface protection -
Powder coated
Type of covering -
Door
Type of door -
Single
Width -
400 Millimetre
Width in number of modular spacings -
14
With lock -
With mounting plate -
ABB

Availability On Request

£185.86
